1.Beds;
2.Molds (one set each for 30, 40, and 50 angle irons);
3.One set of hydraulic system;
4.One set of control system.
1.When programming, simply enter the workpiece size, alignment distance, and number of workpieces, or use the program data generated by the release software directly.
2.Using the production surface storage, record query and selection functions, you can directly select records to complete the process.
3.Take many measures to solve angle bends caused by feeding difficulties and alignment errors.
4.PLC industrial control machine control, servo motor feeding, high efficiency, and stable work precision are adopted.
5.All major hydraulic, gas and electrical components are imported products.
6.With fault self-diagnosis and data statistics function.
7.The cutting tools and punching dies are made of SKH51 material from Japan and vacuum heat treatment, which obviously improves service life.
| Model number | Throughput | Height of angle iron (mm) |
Production speed | Power (kw) | Machine size (mm) | Weight (kg) |
| WY-JG-50 | 3.50-5.0 | 30/40/50 | 2.5min/angle iron | 7 | 4300x1000x1750 | 500 |
